Curious
seismic
events recorded at EPSO,
Coonabarabran, NSW.
Date |
Time
(UTC) |
What |
Summary Seismogram |
PSN data file |
Media |
2018-08-16 |
18:21:30 |
An Mw=6.0 earthquake in the Volcano Islands
(Japan region) was followed 82 seconds later by another
quake of Mw = 6.4. This double earthquake
occurring in the same location had the visual
appearance on EPSO's traces, of a NSW regional
earthquake, with an 82 second delay between P and S
phases. |
S6000
triaxial EPSO Array |
psn psn |
|
2018-03-08 |
10:42:43 |
A double earthquake in the immediate
vicinity of the Cadia gold mine, with two (1,
2)
ML=2.7 quakes located in the same area separated by 10
seconds. |
S6000
triaxial EPSO Array |
psn psn |
1,
2 |
2018-02-28 |
02:30 |
A roadworking vibrating roller which was
operating between 100-1000m from our house, caused the
whole house to noticeably vibrate. The primary
vibration detected on EPSO Array shows a fairly
monochromatic frequency of ~29Hz, which excited various
sympathetic modes of vibration in our house. |
EPSO
Array |
psn |
|
2017-10-26 |
08:30 |
An exceptionally intense wind storm that
abruptly arrived from nowhere and lasted for around 15-20
minutes. Large transient spikes on the traces were
from a number of nearby large trees toppling. |
S6000
triaxial EPSO Array |
psn psn |
|
2017-10-22 |
04:28:50 |
A horse walking nearby an EPSO Array
sensor. A visiting horse strolled past an EPSO Array
sensor and the characteristic seismic noise was
recorded. Because of a walking horse's step-pattern
the resultant seismic waveform looks a little muddled, but
frequency analysis shows a sharp peak amplitude of around
1.65Hz, implying a footstep every 0.6 seconds, implying
each leg of the horse stepping with a period of around 2.4
seconds. |
EPSO
Array |
psn |
|
2017-09-03 | 03:30:05 |
North Korean underground nuclear explosion
from the Punggye-ri
Nuclear Test Site, located
8300km north of EPSO. This event was similar to
earlier events recorded in 2016 but of much larger
amplitude. A detailed description of EPSO's
observations are recorded on a separate
page. |
|||
2017-07-20 |
02:49:00 |
Heavy plant operating around 1km due west
of us. |
EPSO
Array |
psn |
|
2017-02-26 |
21:10:00 |
Often at around 7-8am local time, EPSO
records a local noise starts which persists for an hour or
two, the source of which is heavy equipment operating at
our town's dump located ≈3km away. Attached is a 20 minute
example of the noise recorded by EPSO Array, generated by
a D7 bulldozer chewing into sandstone rock at a range and
heading of 3.3km and 72º. The noise has a fairly
sharp spectral peak of around 7Hz. |
EPSO
Array |
psn |
|
2016-11-13 2016-11-14 2016-11-15 |
11:32:09 11:52:47 13:21:13 13:31:30 18:59:07 22:19:32 00:34:23 06:47:54 07:21:05 17:30:33 |
Following the M7.9 quake below, there were numerous large aftershocks located in the north-eastern region of the South Island of New Zealand, and many of these quakes transmitted hydroacoustic T-phase waves into the Tasman Sea. T-phase producing quakes varied in size between M5.2 to M6.2, and what this earthquake sequence has demonstrated is that any land based earthquake occurring in New Zealand's South Island with a magnitude of ≈5.2 or greater, is likely to generate a T-phase into the Tasman Sea, which then arrives in south eastern Australia around 20-25 minutes later. The psn files shown to the right are all of 30 minutes duration and have been band-pass filtered between 1-4Hz. | S6000 triaxial S6000 triaxial S6000 triaxial S6000 triaxial S6000 triaxial S6000 triaxial S6000 triaxial S6000 triaxial S6000 triaxial S6000 triaxial |
psn psn psn psn psn psn psn psn psn psn |
|
2016-11-13 |
11:03:01 | A T-phase event from a Mwp=7.9 earthquake located on the east coast of the South Island of New Zealand, Extraordinarily, the quake that caused it was located on land on the eastern side of New Zealand , around 140km from the nearest western coastline. Further details at EPSO's T-phase log for 2016-11-13. | VM hor acceln VM hor velocity EPSO Array |
psn psn psn |
|
2016-10-27 |
03:38:47 |
Quarry blast at the nearby Warrumbungle
Shire Council blue-metal rock quarry. Initial
frequencies peaked at around 18Hz, which after a few
seconds gave way to surface waves of 2-3Hz. This may
be compared with an earlier blast at the quarry that
occurred on 2014-11-06. |
S6000
triaxial EPSO_Array |
psn psn |
|
2016-09-09 |
00:30:01 |
North Korean underground nuclear explosion
from the Punggye-ri
Nuclear Test Site, located
8300km north of EPSO. The seismic signal was
weak (peak vertical ground speed < 1µm/s) but
clear, being the first few cycles of the initial
P-phase. A separate
web page gives a more detailed account of the
observations at EPSO, and from elsewhere. |
S6000 triaxial EPSO_Array Willmore Z |
psn psn psn |
|
2016-01-06 |
01:30:01 |
North Korean underground nuclear explosion from the Punggye-ri Nuclear Test Site, located 8300km north of EPSO. The seismic signal was weak (peak vertical ground speed < 1µm/s) but clear, being the first few cycles of the initial P-phase. A separate web page gives a more detailed account of the observations at EPSO, and from elsewhere. | S6000 triaxial EPSO_Array |
psn psn |
|
2015-12-20 |
10:21:21 |
We are surrounded by a forest largely
comprised of the tree species Eucalyptus
Rossii, known locally as 'scribbly
gums'. This species has a notorious tendency to
randomly drop large branches, also giving it the generic
title of 'widow maker'. We occasionally hear loud
crashes in the distance caused by falling timber,
particularly during times when the trees are stressed by
drought. These events generally record well on EPSO
Array, such as with the example shown (located somewhere
in our north-east sector). These data also address
the age old philosophical question "If
a tree falls in a forest and no one is around to
hear it, does it make a sound?" The answer is, "you
bet it does!" |
EPSO
Array |
psn |
|
2015-10-19 |
22:05:00 |
A series of pulses spaced every ≈3.7s,
lasting for around 6 minutes, with this grouping repeated
several times during the daylit hours. The source is
very likely a tractor-mounted machine which rams
fence-posts into the ground by repeatedly striking them
with a heavy weight.. Analysis
of the EPSO Array data showed a source direction of
188° and an apparent velocity across the array of 1.0km/s
(this low seismic velocity is typical of surface waves
from very nearby sources). The peak spectral energy
was at a frequency of ≈15Hz which is also typical of very
local events. |
S6000
triaxial EPSO Array |
psn psn |
|
2015-03-12 |
22:51:42 |
Large tree branch collapse located
immediately north of EPSO Array (-31.25841,
149.21993) |
S6000
triaxial EPSO Array |
psn psn |
|
2015-02-25 |
12:29:55 |
Another seismic T-phase from a M4.8 earthquake in New Zealand, with the Geonet epicentre location around 75km west of Te Anau. More details from the EPSO T-Phase log. | S6000
triaxial EPSO Array |
psn psn |
|
2015-01-13 |
11:40:01 |
Another seismic T-phase from a M5.5 earthquake in New Zealand, with the Geonet epicentre location around 25km inland from the open ocean. More details at the EPSO T-Phase log. | EPSO
Array |
psn |
|
2015-01-05 |
17:48:41 |
Yet another seismic T-phase associated with
an earthquake from the southern New Zealand region, but
this time from an event located
inland about 40km from the nearest coast.
More details at the EPSO
T-Phase log. |
VM
hor acceln VM hor velocity S6000 triaxial EPSO Array |
psn psn psn psn |
|
2014-12-31 |
02:20:00 |
A strange
looking pulsing visible on the 24h summary traces,
starting at around 02:10UTC (13:10EDT) and lasting for
about an hour. The pulsing pattern repeats every 60
seconds or so. Analysis by EPSO
Array shows a very consistent apparent bearing to
the noise, of 56°, with Vapp = 1.2km/s, and a
peak frequency of 6.2Hz, with half-power bandwidth of
around 0.4Hz. The apparent speed and direction are
consistent with operation of heavy equipment 'out in the
scrub' within a few kilometres distance. |
S6000
triaxial EPSO Array |
psn psn |
|
2014-12-12 |
08:02:07 |
Yet another seismic T-phase has arrived
from our local T-phase 'nursery' located SW of the South
Island of New Zealand. USGS reported an event had
occurred at 08:02:07, located at -46.963,
165.832 and although no usual seismic phases were
detected at EPSO, around 22 minutes after the event
(≈08:24:05) an apparent T-wave arrived. A quick
check of the relevant EPSO Array data showed the arrival
direction of these waves was almost identical to the event
recorded on 2014-12-01 described immediately below. |
S6000
triaxial EPSO Array |
psn psn |
|
2014-12-01 | 13:04:27 | A seismic T-phase from an undersea
earthquake located in the Auckland
Islands Region of New Zealand. This T-phase
event was very similar to another which occurred in the same
area around a year earlier, but this latest event
was recorded by EPSO
Array and apparent arrival angles of various
earthquake waves may now be estimated. There has
been some speculation that the T-waves may preferentially
originate from particularly steep sections of the
Australian continental shelf, where the ocean sound waves
are more efficiently converted to a seismic P-wave in the
crust. Thus T-waves may arrive in somewhat different
directions from the usual P and S phases. However,
for this particular event the P-phase and T-phase had
identical apparent arrival directions, suggesting that the
conversion from ocean-acoustic to seismic-P occurred at
the coast somewhere along the great circle track between
EPSO and the earthquake. Inspection of an undersea
map of this coastal area shows that the continental
shelf is relatively steep and oriented approximately
perpendicular to the earthquake's great circle track, so
it is perhaps not so surprising that the P and T waves
recorded by EPSO Array had very similar arrival
directions. |
VM hor acceln VM hor velocity S6000 triaxial EPSO Array |
psn psn psn psn |
|
2014-11-06 |
04:12:34 |
Quarry blast at the nearby Warrumbungle Shire Council blue-metal rock quarry. Initial frequencies peaked at around 18Hz, which after a few seconds gave way to surface waves of 2-3Hz. | S6000 triaxial EPSO Array |
psn psn |
|
2014-10-11 |
03:20:00 |
A thunderclap from a nearby 'sneaky'
thunderstorm cloud caught me by surprise. The
associated lightning bolt was observed to occur in a WNW
direction at an elevation of around 30° (i.e. worryingly
close). Analysis of this seismic 'event' from EPSO
Array indicated a source direction that agreed
nicely with what was observed visually (calculated source
direction = 277°). Moreover the apparent velocity of
the wave front across the array was estimated at around
500m/s which is what would be expected from sonic plane
wave fronts traveling at the speed of sound in air when
impacting the ground at an elevation of about
30°. Curiously, the township of Coonabarabran
and surrounding districts were rocked by a loud
unexplained acoustical rumbling in 1896.
Should such an event occur again a precise source
direction, and perhaps also an elevation, may be
determined. |
S6000
triaxial EPSO Array |
psn psn |
|
2014-07-08 |
02:07:36 |
A mining blast from either Boggabri or
Tarrawonga open cut coal mines, located around 130km ENE
of EPSO. What is unusual about this particular blast
event is the conspicuous arrival of what appear to be
Rayleigh waves following the initial P and S
arrivals. This effect is most evident in the EPSO
Array data which was generated by vertically oriented
geophones whose natural period is around one second.
The peak spectral amplitude during P-phase arrival was
around 10Hz and S-phase around 2Hz. The frequency of
the Rayleigh waves (if that's what they were) was around
0.63Hz. |
S6000
triaxial EPSO Array |
psn psn |
|
2013-12-16 |
12:07:27 |
A Mb=5.3 earthquake located
off the West Coast of the South Island of New Zealand
generated a conspicuous T-wave, with the T-wave arriving
at EPSO around 16.3 minutes following the initial P-Wave
(a very similar event occurred at 2012-03-14 19:07:44UTC -
see
below for details). For the first time such an
event was also captured by the EPSO Array and served as a
good system test. The initial deep Earth P-waves
from this event passed the EPSO Array with an apparent
horizontal velocity of ≈13km/s, implying that the true
wave fronts impacted the array from the deep Earth with an
inclination angle of ≈60º with respect to the EPSO Array
ground surface. The later T-wave originated
somewhere near the Australian continental shelf, at a
distance of ≈400km. The T-wave passed over the EPSO
Array with an apparent horizontal velocity of ≈8km/s,
implying that the true wave front had an inclination angle
of around 40º, as one might expect from a much closer
event. |
VM
hor acceln S6000 triaxial SS-1 vertical EPSO Array |
psn psn psn psn |
|
2013-08-28 |
04:03:23 |
A routine mining roof collapse from bord-and-pillar
mining (also known as room-and-pillar
mining). Mining collapses are commonly recorded at
EPSO, but what makes this particular event interesting is
that the precise mine whereabouts and scale of the
collapse were known in some detail. The geographic
distance to the mine site is ≈285km from EPSO, but the S-P
analysis indicates a 250km range, so in this case WinQuake's velocity
tables for NSW regional quakes (at depth=0) are
underestimating the true range by ≈12%. The
collapsed mine roof had and estimated area of 5200m2,
located at a depth of ≈100m, which dropped by a distance
of ≈2.5m. So assuming the overburden rock (a mixture
of shale and sand) had a specific gravity ρ≈2.2 then the
total mass of the body that dropped was around 1.1×106
tonnes, or 1.1×109 kg, and for this mass to
drop 2.5m would release around 2.9×1010 Joules
of energy. Using the formula
relating earthquake magnitude 'M' to energy released 'E',
where E≈6.3×104×103M/2 , and for
EPSO's Richter [Local] Magnitude estimate of the event of
ML=2.9, the energy released by the event was
around 1.4×109 Joules. This figure
is ≈4.9% of the preceding estimate so it seems
likely that figures for the mine roof area and the size of
the vertical drop were somewhat overestimated, and/or the
roof did not fall as one solid lump. But the biggest
unknown in these calculations, is how much mechanical
energy from the rock fall actually gets transferred into
seismic waves, and doesn't simply get transferred into
heat by the fracturing of rock. The above
calculation suggests this figure might be around 5%,
although a small variation in estimated ML
could have a large bearing on this figure. |
S6000
triaxial |
psn |
|
2013-05-27 | 01:11:56 | A presumed mining blast where the maximum
amplitude of the vertical component of the P-wave was
around 3× that of the S-wave. Typically, as one may
observe when browsing the codas of EPSO
logged mining blasts, the peak amplitude of the
vertical component of the P-wave is ≈0.5-1× that of the S,
making this particular event rather unusual. Similar
observations of the vertical component amplitude were
recorded by a Sydney station. |
S6000 triaxial Sydney vertical |
psn psn |
|
2012-12-21 |
15:26:21.8 | A doublet
earthquake, with a ML=1.9 earthquake (OT≈15:25:31)
followed ≈51seconds later by a ML=2.9 event. The
larger event was located by the ASC
with OT=2012-12-21 15:26:21.8 (±3s)‚ position= -32.49±0.08°,
152.02±0.21°, depth=14±11km, around 20km SW of the
township of Buledelah, NSW. The position calculation
utilised data from seismic stations DUNG, REDH,
EPSO,
MGCD
and RNDA.
A similar doublet occurred with the Lake
Keepit quakes, on 2012-06-08. |
S6000 triaxial SS-1 vertical |
psn psn |
|
2012-06-25 | 05:30:34 | Peculiar looking seismic
coda, from two closely located and co-timed mine blasts
(from Wilpinjong & Ulan Colliery). The
superposition of seismic phases produces a misleading S-P
arrival which initially indicated a range (to me at least)
of 76km, whereas the mines are actually located at
distances of 121 and 135km from EPSO. |
S6000 triaxial SS-1 vertical |
psn psn |
|
2012-06-22 | 09:16:04 | The largest earthquake
measured in Victoria for many years, occurring nearby the
Gippsland township of Moe, estimated at ML=5.4
by Geoscience Australia and one of the 12
strongest ever recorded in Victoria. It was widely
felt in Victoria and southern NSW, and reported
internationally. The epicentre was located
around 16km from a
large open-cut coal mine and associated power
station. |
VM hor acceln VM hor velocity FBV Z velocity S6000 triaxial SS-1 vertical |
psn psn psn psn psn |
|
2012-06-08 | 11:31:05 | A large local event
(ML≈4.8) occurred ≈130km from EPSO, nearby
Lake Keepit, a 425 gigalitre man-made reservoir
created by Keepit
Dam. This event was followed 98 seconds later
by a ML≈4.6 event at the same location. The
earthquakes were felt strongly in the NSW towns of
Gunnedah and Tamworth, with some minor damage
reported. Reports of shaking were widely
recorded in the region, and it was felt in our local
township of Coonabarabran (130km distant from the
epicentre) where it was reported
in the Coonabarabran Times newspaper. Geoscience
Australia maintain a publicly accessible database of
all significant Australian earthquakes recorded since
1955. An interrogation
of the database for 50km surrounding Lake Keepit since
1956 shows that there has been little seismic
activity in the surrounding area since the dam's
construction in 1960, of which the 8th June 2012 quake was
by far the largest. This quake was followed by
several aftershocks, which are posted on EPSO's
log of Australian events. |
VM hor acceln VM hor velocity FBV Z velocity S6000 triaxial SS-1 vertical |
psn psn psn psn psn |
|
2012-05-08 |
11:26:40 | A small ≈M1.3 event located
at around 51km from EPSO. But this event was also
weakly recorded at ARMA and CMSA,
from which the ASC
computed an approximate epicentre position of -30.92,
149.30, and a depth of 28km. This is only 12km
distant from the best estimated epicentre location* of -30.83,
149.37 for the 1969
M5.0 Coonabarabran Earthquake (*McCue, 2011).
This 1969 event was one of the 12
strongest earthquakes ever recorded in NSW, and did
minor damage to Coonabarabran township. |
S6000 triaxial | psn | |
2012-04-11 | 08:38:32 | Gigantic Magnitude 8.6
Earthquake located off the West
Coast of Northern Sumatra, Indonesia. This
event's epicentre was along the same fault which caused
the devastating Boxing
Day Earthquake and tsunami of 26th December 2004,
but due to the strike-slip
nature of the fault's surface rupture, no large
displacement of seawater occurred and the resulting
tsunami was small. At EPSO, located some 7000km
distant from the epicentre, the ground moved backward and
forward with a peak displacement amplitude of 4.3mm, with
a period of around 27 seconds. This may be compared
with the 1.4mm displacement caused by the Tōhoku
earthquake of 11th March 2011, and the 2.4mm
displacement caused by the Chile
Earthquake of 27th February, 2010. It's
unlikely I'll ever again see such a large ground
displacement at EPSO from any event, overseas or
otherwise. |
VM hor acceln VM hor velocity VM hor acceln (+/- 12h) |
psn psn psn |
|
2012-03-23 | 09:25:14 | The biggest Australian
earthquake for around a decade. This Magnitude (Mw
5.4) event occurred nearby the remote settlement of Ernabella, South
Australia. Robert
Herrmann’s moment tensor analysis for this event may
be found here.
GA's
ML
estimate was 5.7, whereas my ML (referenced to my Ranger
SS-1 Vertical instrument) was 4.6. |
VM hor acceln VM hor velocity FBV Z velocity S6000 triaxial SS-1 vertical |
psn psn psn psn psn |
|
2012-03-14 |
19:07:44 |
A relatively small quake
off the Off W Coast of
South Island, New Zealand, appears to have generated
a conspicuous T-wave,
where acoustical water waves have been generated on the
sea floor by the earthquake, and propagated until they
encountered Australia's continental shelf, where some of
the acoustical energy was converted back to seismic
waves. The Great Circle distance from EPSO to this
earthquake's epicentre is 2174km. The distance
from EPSO to the edge of the Australian continental shelf
(on the direct EPSO-earthquake track) is about
380km. From this
location, a seismic P-wave takes around 54 seconds
to travel to EPSO. By analysing the right-hand
seismic traces, the delay between the earthquake's origin
time (19:07:44) and shaking commencing at EPSO (19:28:44)
resulting from the T-wave arrival, is around 1260
seconds. Assuming this shaking was due to T-waves
traveling via the direct Great Circle track and impacting
the Australian continental shelf offshore from Sydney,
these waves were propagating in the ocean for 1260-54=1206
seconds and covered 2174-380=1794km. In this case
the derived speed of the T-waves is 1206/926=1.3km/s in
the ocean. But if the T-waves impacted the
Australian continental shelf at the closest point to the
epicentre (i.e. eastern
Tasmania, 1480km distant from the epicentre, and
1280km from EPSO), from this location a seismic P-wave
would take around 167 seconds to travel to EPSO. So
via this route, the T-waves would have propagated for
1480km for 1206-167=813 seconds, suggesting a T-wave
propagation velocity of 1.8km/s. Therefore the ocean
T-wave propagation speed is in the range
1.3-1.8km/s. The average of these two limits is
around 1.5km/s which is approximately the speed
of sound in seawater, and is consistent with the
propagation of the T-waves waves via the so called SOFAR
channel. Most of the spectral energy in the
T-wave induced shaking observed at EPSO, is contained
within the 1.5-2.6Hz spectral band. |
S6000 SS-1 vertical |
psn psn |
|
2012-01-05 |
06:00:00 |
Vertical motions recorded
from EPSO's new Inyo
Force Balance Vertical (FBV) instrument, during the
passage of an intense overhead thunderstorm. At this
time the FBV instrument was not barometrically isolated
and therefore susceptible to detecting perturbations in
atmospheric pressure, which were considerable during the
passage of the storm. The FFT spectrum of this 40m
dataset, shows pressure perturbations peaking in amplitude
at around a 60s period. |
Inyo
FBV |
psn |
|
2011-12-04 | 19:04:42 | Small ML=0.3 event at 47km
range from EPSO, with striking similarity to an event
logged 2011-05-16
10:40:57 The range and general appearance of
these two trace codas are extremely similar, and the
3-axis traces for the first 0.2s are practically
identical, suggesting the events have a common
origin. Analysis of the initial P-wave arrival by
the ASC
indicates that the event location was in a general
eastwards direction from EPSO, which is in an area
of ancient volcanism, quite
interesting to drive through. |
S6000 triaxial | psn | |
2011-12-02 |
01:31:36 |
Presumed mining blast from
around -32.62,
151.17 (ASC)
but with unusually strong low frequency components which
registered unusually strongly on Volksmeter long period
instrument. S-6000 ML=2.3, Volksmeter ML=3.5. |
S6000 VM hor acceln VM hor velocity |
psn psn psn |
|
2011-11-22 |
18:05:12 |
Arrival of P-waves from a
M6.6 quake in Beni, Bolivia. This arrival had
an initial strong vertical peak velocity of 7.6μm/s, of frequency
around 2.5Hz. Significant amplitude long period
waves (i.e surface waves) didn't follow this arrival, an
effect which is caused by the quake's great depth,
of about 533km. |
S6000 |
psn |
|
2011-10-14 |
11:29:45 |
Nearby thunderclap recorded
on Sprengnether S-6000 |
S6000 |
psn |
|
2011-10-11 |
03:30:00 |
D4 Bulldozer working a few
metres from EPSO's vault. This induced several
northward-falling step functions in VM tilt, and peak
ground velocities of around 70-75um/s horizontally and
17um/s vertically. |
VM
hor acceln S6000 |
psn psn |
|
2011-10-05 |
05:00:00 |
D4 Bulldozer clearing
firebreaks 270-440m from EPSO's vault. |
S6000 | psn | |
2011-08-10 |
02:27:48 |
Possible ML=2.0 Mining
Blast, apparently from range=249km, but with unusually low
frequency components. |
VM
hor acceln VM hor velocity L15B triaxial SS-1 vertical |
psn psn psn psn |
|
2011-07-29 |
00:10:00 |
Our neighbour chopping
wood, 220m distant. |
SS-1
vertical |
psn |
|
2011-07-27 |
23:55:00 |
Our Toyota sedan car returning up our driveway. | L15B
triaxial SS-1 vertical |
psn psn |
|
2011-07-27 |
22:45:00 |
Our Toyota sedan car
departing down our driveway. |
L15B
triaxial SS-1 vertical |
psn psn |
|
2011-07-18 |
09:00:00 |
Relatively weak microseismic noise. Volksmeter RMS acceleration = ~0.4um/s/s & RMS velocity = ~0.25um/s. Peak period = 4-7s. Ranger SS-1 Geophone (vertical) RMS velocity = ~6nm/s. 60m records | VM
hor acceln VM hor velocity SS-1 vertical |
psn psn psn |
|
2011-06-21 |
14:49:31 |
Step function change in
EPSO's pier tilt, toward the North. |
VM hor acceln | psn |
|
2011-06-21 |
14:30:05 |
Step function change in EPSO's pier tilt, toward the South East. | VM hor acceln | psn |
|
2011-06-04 |
23:00:00 |
Exceptionally strong
microseismic noise. Volksmeter RMS acceleration =
~1.1um/s/s & RMS velocity = ~1.4um/s. Peak
period = 7.4s. Ranger SS-1 Geophone (vertical) RMS
velocity = ~9nm/s. 60m records. |
VM
hor acceln VM hor velocity SS-1 vertical |
psn psn psn |
|
2011-05-30 |
12:37:08 |
Step function change in
EPSO's pier tilt, toward the South East, following a
period of light rain (13mm total). |
VM hor acceln | psn |
|
2011-05-22 |
16:42:24 |
Two small teleseismic
quakes (from the Philippines) arriving concurrently to
give the impression of a nearby regional event. |
SS-1
vertical |
psn |
|
2011-05-16 |
10:40:57 |
ML=0.9 Small event at
~47km range |
L15B
triaxial SS-1 vertical |
psn psn |
|
2011-04-19 |
06:05:00 |
Chopping
firewood, 35m NE of EPSO, Australia |
L15B
triaxial SS-1 vertical |
psn psn |
|
2011-04-18 |
19:37:51 |
Passing kangaroos.
Note the constant
pulse
repetition frequency. |
L15B
triaxial SS-1 vertical |
psn psn |
|
2011-04-14 |
08:22:13 |
Step function on Volksmeter
N-S acceleration channel, most likely due to friction from
electrostatically charged dust bridging Volksmeter
pendulum and capacitor plates. |
VM hor acceln | psn |
|
2010-12-30 |
09:27:04 |
18m-tall 1-ton tree felled
35m NE of EPSO, Australia. Caused a step-function on
Volksmeter acceleration trace |
VM
hor acceln L15B triaxial SS-1 vertical |
psn psn psn |
|
2010-12-25 |
14:50:30 |
Mysterious strong overnight
twangs, strongly N-S polarised (geophone rotated 90
degrees, so apparent E-W channel is N-S) |
L15B triaxial | psn |
|
2010-12-24 |
07:36:10 |
15m-tall tree felled 30m NE
of EPSO |
L15B triaxial | psn |
|
2010-12-23 |
17:38:13 |
Mysterious strong overnight
twangs, strongly N-S polarised. |
L15B triaxial | psn |
|
2010-11-10 |
17:24:38 |
Nearby lightning strike |
SS-1 vertical
|
psn |
|
2010-10-23 |
16:48:57 |
Large tree limb falling,
about 100m NW of EPSO |
L15B triaxial | psn |
|
2010-10-15 |
22:25:00 |
Exceptionally strong
microseismic noise |
SS-1 vertical | psn |
|
2010-10-11 |
23:32:00 |
Our clothes washing machine
commencing 980rpm spin cycle |
L15B hor velocity | psn |
|
2010-09-24 |
16:42:21 |
Passing kangaroo or wallaby |
SS-1 vertical | psn |
|
2010-01-02 |
00:00:00 |
Nearby creek (220m distant)
in major flood |
SS-1 vertical | psn |
